TellerScan TS240
Specifically designed for high volume transaction, The TellerScan TS240 is everything you could want in a professional cheque scanner. With the automatic document feeder, this cheque scanner helps you speed up the cheque scanning process and offers steady performance for a demanding workload.
TS240 comes with enhanced image-capture technology that balances fast speed with exceptional results across a wide variety of scanning situations. Built to last using premium parts and material, it offers reliability and high productivity all in one sleek and compact device, thus remains as the most popular and versatile cheque scanning device in the world.
Benefits
The TS240 bring many benefits to your business, expanding from your staff to your customers:
Improved Business Productivity
TS240 eliminates the need for all of the time-consuming and tedious tasks related to high volume of cheque processing, as it provides faster and better paper scanning that allows you to scan hundreds of cheques in a matter of minutes, thus improving the quantity and quality of your business productivity.
Enhanced Overall Scanning Quality
With its outstanding scanning speed and imaging results, TS240 produces the best and clearest image possible and elevates common scanning process to a whole new level.
Automatic Information Storage
TS240 uses magnetic ink character recognition to quickly read, capture, and save the data from cheques. All of this information is automatically & digitally stored and organized in a database. The database can be exported and made available over your network so with just a few clicks, you can easily manage, retrieve, or file the information in a fraction of time as needed.
Everlasting Data Quality
Information on documents are constantly degrading, through constant use and general aging (torn, faded, and possibly brittle). With the reliable TS240, you are able to capture the original cheque image in high quality, thus avoiding degradation of quality that usually accompanies physical documents.
Increased Security
With the TS240-UV, TellerScan® also offers advanced UV imaging technology to help you increase profit while reducing loss due to counterfeit cheques. The automatic cheque feeding also ensures a faster process as it eliminates the need to visually inspect the cheques or other security documents.
Features
Highly Durable
Engineered to last with high quality parts and materials, the TS240 smartly combines durability and high productivity as it offers stable performance for heavy duty daily cycle.
Selectable High-Speed Scanning with High-Quality Result
Regardless of the scanning environment, the TS240 delivers fast yet reliable performance while offering high-speed scanning of up to 150 pages per minute in vivid color, greyscale, and monochrome with perfect image quality. Four selectable scanning speeds are available (starts from 50, 75, 100, and 150) to give more flexibility in balancing between the processing speed & image quality according to business requirements.
Concurrent Two-Sided Scanning System
Despite being a relatively compact scanner, TS240 allows you to do a double-sided scan in a single step.
Automatic Document Feeder
With automatic document feeder that holds up to 100 cheques per batch, TS240 requires minimal staff intervention thus significantly saving time, improving user experience, and minimizing potential human error.
Hassle-Free Maintenance
With easy-to-change and easy-to-clean polymer rollers, ongoing maintenance routine can be handled manually by user, thus eliminating the need for frequent service calls and allow you to boost scanning efficiency.
| Parameter | TellerScan® TS240 |
| Unit Size | Height: 7.5" (19.05cm) Width: 5.10" (28.19cm) Length: 11.10" (12.95cm) Weight: 5.20 lbs. (2.4kg) |
| Scanning Speed | Four different speeds available: Up to 50, 75, 100 or 150 documents per minute |
| Supported Operating System | Windows 10® (32 / 64 bit) Windows 8.x® (32 / 64 bit) Windows 7® (32 / 64 bit) Windows Vista® (32 / 64 bit) Windows® XP Mac OS X® Linux OS |
Related products
MICR Cheque Reader, Sorter and Image Scanner (FZA-3165 / FZA-3166)
FZA-3165 / FZA-3166
MICR Reader with Image Scanner This unit features a document feeder (auto feeder/auto hopper) with a capacity of 500 documents, an ultrasound double detector, a high performance MICR reader, IJP rear endorser and front/rear CCD Image cameras. * FZA-3165 --- without Rear endorser* FZA3166 --- with Rear endorserFZA-2070
MICR Encoding module This unit is the option for the E13B MICR encoding with a speed of up to 60 DPM.FZA-3066
Sorting pocket module This unit can be equipped with 3 modules of 12 sorting pockets (up to 36 pockets).Technical Specifications
FZA3165 / 3166 (MICR Reader, Endorser and Image Scanner) MICR Encoding module This unit is the option for the E13B MICR encoding with a speed of up to 60 DPM.FZA-3066
Sorting pocket module This unit can be equipped with 3 modules of 12 sorting pockets (up to 36 pockets).Fuji FZ-1027
RDM MICR Qualifier GTX
Features
- Report Generation
- Graphical representation of ANSI character dimensions
- PDF file formats of analysis screens
- Save data to disk
- Embedded PDF reporting
- Dimensional waveform analysis
- Character spacing data table
- Extraneous ink detection
- French language format avaialble
- 100 inch/second transport speed
- ANSI specified read/write head and amplifier
- Test entire 5/8” clear-band
- Power Supply: 115 VAC, 60 Hz; 220, 240 VAC 50 Hz
- Weight: 27 lb.
- Dimensions: 13”(W) x 8” (H) x 10” (L)
- Pentium IV, 200 MB available hard disk space
- Windows 2000/XP/Vista
- 1024 x 796 video set to 256 colors
- Windows supported printer
Fuji FB-30
- Processing Speed up to 85 DPM (standard 6.7 inches document)
- Auto hopper / single stacker capacity - max 100 sheets
- MICR reading (CMC7/E13B)
- Ink-jet printer for rear endorsement
- High quality colour, greyscale and black and white 300 dpi images
- Single feed for plastic non-embossed card scanning (ID, license card)
- UV image scanning (option)
- Ultrasonic double feed detection for special paper (option)
- PC interface – image data and controls via USB 2.0
- Operating system – Windows XP / Vista / 7 / 8
| Type (options) | Included features |
| FB-30 | Standard unit |
| FB-30 S | With Ultrasonic double feed detection |
| FB-30 U | With UV image scanning |
CheXpress CX30
FZA-2155 (BP63)
* Integration to CIF and cheque inventory requires further discussions RDM EC7000i Series
- Includes all of the industry leading features of RDM’s EC6000i Series
- Captures a high-quality two-sided binary image of the cheque in seconds
- Lowest cost two-sided imager in the industry
- Optional Franking Acknowledgement Printer
- Utilizes RDM’s patented Progressive MICR Method delivering the highest MICR read rate in the industry
- Optional bi-directional Magnetic Stripe Reader (MSR)
- Standard USB connectivity provides flexible connection to PC-based applications
- Standard 2-year manufacturer warranty
